| TECHNICAL SPECIFICATIONS |
| Output |
| Output Power Capacity |
500 Watts / 750 VA |
| Max Configurable Power |
500 Watts / 750 VA |
| Nominal Output Voltage |
120V |
Output Voltage Distortion |
Less than 5% at full load |
Output Frequency (sync to mains) |
47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal |
| Crest Factor |
up to 5 : 1 |
| Waveform Type |
Sine wave |
| Output Connections |
(6) NEMA 5-15R |
| Input |
| Nominal Input Voltage |
120V |
| Input Frequency |
50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections |
NEMA 5-15P |
| Cord Length |
6 feet (1.83 meters) |
| Input voltage range for main operations |
82 - 144V |
| Input voltage adjustable range for mains operation |
75 - 154V |
| Batteries & Runtime |
| Battery Type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
|
| Typical recharge time |
3 hour(s) |
| Replacement battery cartridge |
RBC48 |
| RBC™ Quantity |
1 |
| Typical Backup Time at Half Load |
15.9 minutes (250 Watts) |
| Typical Backup Time at Full Load |
4.6 minutes (500 Watts) |
| Runtime Chart |
Smart-UPS |
| Communications & Management |
| Interface Port(s) |
DB-9 RS-232,Smart-Slot,USB |
| Available SmartSlot™ Interface Quantity |
1 |
| Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
| Audible Alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
| Emergency Power Off (EPO) |
Optional |
Surge Protection and Filtering
|
| Surge energy rating |
540 Joules |
| Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
|
| Maximum Height |
6.20 inches (157 mm) |
| Maximum Width |
5.40 inches (137 mm) |
| Maximum depth |
14.10 inches (358 mm) |
| Net Weight |
29.00 lbs. (13.18 kg) |
| Shipping Weight |
32.00 lbs. (14.55 kg) |
| Shipping Height |
11.00 inches (279 mm) |
| Shipping Width |
10.75 inches (273 mm) |
| Shipping Depth |
19.50 inches (495 mm) |
| Color |
Black |
| Units per Pallet |
40.00 |
| Environmental |
Operating Environment |
32 - 104 °F (0 - 40 °C) |
Operating Relative Humidity |
0 - 95% |
| Operating Elevation |
0-10000 feet (0-3000 meters) |
| Storage Temperature |
5 - 113 °F (-15 - 45 °C) |
| Storage Relative Humidity |
0 - 95% |
| Storage Elevation |
0-50000 feet (0-15000 meters) |
| Audible noise at 1 meter from surface of unit |
55 dBA |
| Online Thermal Dissipation |
90.00 BTU/hr |
| Conformance |
| Regulatory Approvals |
BSMI,CSA,FCC Part 15 Class A,UL 1778,UL Listed,VCCI |
| Standard Warranty |
2 years repair or replace |
| Equipment protection policy |
Lifetime : $150000 |
| |
